Map of Mars’ south polar ice. The colors show how thick the ice is, and the black rectangle shows the location of the newly discovered sub-surface lake. From Orosei et al. (2018).

As summer winds down and we prepare for the fall semester, I finally found the time to read the recent announcement about finding sub-surface water on Mars using the MARSIS radar onboard Mars Express.

Although evidence for liquid water on Mars has been reported for a long time, these reports are almost always about ancient flows or very modest, salty trickles (and the presence of water often turns out to be illusory). By contrast, if this most recent report holds up to scrutiny, there could be 10 billion liters of liquid water under the martian south pole.

That’s not much on the scale of the Great Lakes (the smallest one, Lake Erie, contains 10,000 times more water), but it’s more than a thousand times the volume of tanks at the Georgia Aquarium, which hosts more than 100,000 aquatic animals. So the martian lake could easily host a microbial zoo (although no direct evidence for that as of now).

As is common in polar regions on Earth, the martian water lies under kilometers of polar ice and is probably so cold it requires some kind of geological anti-freeze to keep from freezing solid (the kinds of mineral salts that can do the job are actually pretty common on Mars). The overburden pressure from all the ice also helps keep the water liquid.

But the fact that the lake sits underneath so much ice raises an obvious question: how did the scientists spot it in the first place? The answer is related to why the recent wildfires in the west, in addition to fouling the air, have given us very lovely sunsets.

Preferential scattering of blue light by the atmosphere.

When it first leaves the surface of the Sun, sunlight is colored white. But as it passes through the atmosphere, the light (which is a wave of electric and magnetic fields, after all) interacts electromagnetically with the atmospheric gas molecules, which themselves contain electric charges.

The closer the wavelength of the light ray is to the sizes of the molecules, the stronger this electromagnetic interaction and the more the ray can be diverted from its straight path.

Since blue light has a wavelength (500 nanometers) closer to the size of the atmospheric molecules than red light (700 nanometers, it is more readily diverted or scattered. At dusk, as the sun sets, its light has to pass through more and more of the Earth’s atmosphere. So more and more blue light is scattered away, leaving behind more red light and making the Sun look red. If you sprinkle in lots of smoke from a wildfire, you can enhance the coloration.

What does all this have to do with martian lakes? The MARSIS instrument used to find the subsurface lake uses very red radar light, with wavelengths tens to hundreds of meters long. Similar to red sunlight, such long wavelengths can easily pass through even solid rock since they’re much larger than the rocky molecules that make up the martian surface.

Reflectivity of radar light from beneath the martian south pole. The bright patch at the bottom marked with “Basal reflection” is from the sub-surface lake. From Orosei et al. (2018).

This explanation simplifies things a lot, but the upshot is that MARSIS could see the lake as a very unusual bright patch underneath all that polar ice.

What’s next? It’s possible that continued data collection and analysis will turn up other subsurface lakes on Mars. If Mars’ south pole is brimming over with these icy lakes, it could be an especially good habitat for martian microbes. So maybe the effort to find martian life should explore using the same ice drilling technology being considered for exploring the oceans of Jupiter’s moon Europa.

I’m sitting in the hotel lobby at the Woodlands Marriott, waiting for my supershuttle to IAH and recouperating from my second Lunar and Planetary Sciences Conference, LPSC. Before I’m whisked away back to Boise, I thought to write about a few of the fascinating and mind-blowing things I saw this week.

First of all, LPSC is an annual conference that focuses on the geology, geochemistry, and geophysics of planetary science. There’s a lot of focus on solar system bodies with solid surfaces, as opposed to the annual DPS meeting, which has a bit broader focus.

I arrived on Sunday evening and dove immediately in, helping with the First-Timers’ presentation review, an opportunity for new-comers to the meeting to have more senior folks provide feedback on their posters or oral presentations.

Monday dawned cloudy, and I sat through several talks about our sister planet Mars. One that stuck out for me was one about field experiments to explain the perennially mysterious gully formations found on martian slopes with sleds of dry ice.

Tuesday saw me in a session on Saturn’s moon Titan, a cornucopia of geology and atmospheric physics. One particularly impressive talk discussed work to understand how methane deluges on Titan modified the surface.

Tuesday evening, I presented our group’s work flying drones through active dust devils.

Wednesday was packed with talks on sediment transport experiments and analyses, attempting to decipher the martian aeolian cycle, including a neat study of time-lapse imagery of martian dunes.

Thursday was packed with Pluto and results from New Horizons. One talk that stuck in my mind was an analysis of landslides on Pluto’s moon Charon, which, frankly, was a little bit of a tear-jerker. Hard to believe that not one hundred years ago, we didn’t even know Pluto existed. Now we’re trying to understand the system’s geology.

Friday morning wrapped up the meeting with a series of talks about glacial geology on Mars, including a fabulous presentation on mysterious geomorphic features on Mars. Even though these features look for all the world like glacial flow, they appear on totally flat ground, where flow shouldn’t be possible.

And now to catch the shuttle.

Enhanced color image of the thick bands of ice (blue) have been spotted in steep cliff faces. NASA/JPL/UNIVERSITY OF ARIZONA/USGS

At last week’s journal club, we discussed a recent paper that reports the discovery of ancient glaciers on Mars.

Dr. Colin Dundas of the USGS’s Astrogeology Group based in Flagstaff spotted these buried ice cliffs during his daily scan of the regularly collected images taken by the HiRISE camera onboard Mars Reconnaissance Orbiter (MRO) currently circling Mars. (The camera itself is pretty stunning – it produces orbital images of Mars at high enough resolution that you could almost read the headline on a martian newspaper, assuming they had newspapers.)

In scanning through the daily haul of images, Dundas spotted striking blue strata in the walls of steep cliffs just a few meters below the dusty martian surface that sure look like water ice. Follow-up spectral observations by CRISM instrument on MRO confirmed the cliffs were indeed almost completely pure water ice, with no more than with less than 1% dust.

Ice on Mars isn’t particularly surprising – astronomers have known (or at least suspected) there is water ice at the poles of Mars for more than 100 years, and a mountain of data has indicated vast stores of ice in Mars’ subsurface, especially near the poles. But key questions about this ice have persisted: Was the ice recently deposited, and how much dust is mixed in?

Since these newly discovered cliffs are so pure, though, Dundas and colleagues suggest that they were probably deposited as snow before being buried. Mars’ current climate isn’t really conducive to water snow, and so the ice was probably deposited millions of years ago, when Mars’ axis had a very different tilt resulting a very different climate from now. The fact that the ice cliffs occur much nearer to the equator than might be expected also points to formation during a previous climatic epoch.

The implications of these cliffs for Mars’ climate history aren’t entirely clear, but their importance for exploration of Mars is hard to overstate. As Dundas et al. say in their paper, the cliffs would very likely serve as a resource for future human visitors. The water could be combined with gases in the martian atmosphere to make rocket propellent and even oxygen.

So there are large deposits of ice in the subsurface of Mars? Maybe “Total Recall” wasn’t so much science fiction as science prophesy.

Using an Instrumented Drone to Sample Dust Devils

Dust devils are low-pressure, small (many to tens of meters) convective vortices powered by surface heating and rendered visible by lofted dust. The dust-lifting capacity of a devil likely depends sensitively on its structure, particularly the wind and pressure profiles, but the exact dependencies are poorly constrained. In this pilot study, we flew an instrumented quadcopter through several dust devils to probe their structures.

LPSC 2017 Meeting

I’m sitting in my hotel room on the morning after the 2017 LPSC Meeting, trying process all the science that washed over me in the past week. And it was a lot, as you can see by checking out the twitter hashtag #lpsc2017.

From the migration of Martian dune ripples to the global seas on Enceladus, there’s no way for me to do it all justice in one blog post. So instead, I’ll talk about one of the talks that stood out most for me.

On the last day of the conference, Dr. Colin Dundas of USGS gave a mic-droppingly good talk in which he argued very convincingly that Mars’ recurring slope lineae are NOT the result of flowing water. This is a big deal for folks who study Mars but might sound a little arcane for non-Martians.

The animated image above consists of several pictures taken by the HiRISE camera onboard the Mars Reconnaissance Orbiter over several months. The very pronounced dark streaks extending out from the cliff face – those are the recurring slope lineae or RSLs. In many locations on Mars, they recur from one year to the next; they always show up on sloped surfaces; and they are long lines. Hence recurring slope lineae.

Under the current conditions at Mars’ surface, liquid water is not stable over long times, but these dark streaks sure look like small amounts of water running out over the surface, which got people very excited when they were first discovered.

In fact, just a few years ago, some scientists analyzed the spectra of some RSLs and argued they were highly salty brine flows. The salt is important because, even though pure water can’t exist on the surface of Mars, large amounts of salt can stabilize the water, at least for a little while.

This was a huge result, not just because it meant RSLs were small amounts of running water on Mars but because it raised the possibility of much larger sub-surface reservoirs of water. And where there’s lots of water, there could be life.

Well, Dundas’s talk throws all that into doubt. By analyzing the angles of the slopes on which the RSLs occur, Dundas showed that they almost every one of them ended on a slope of about 30 degrees.

Now, if RSLs are flowing water, they should keep flowing, even on small slopes. But if they are some sort of dry granular flow instead, you would expect them to stop once they reached the angle of repose, which is about 30 degrees.

Dark streaks on the sides of Martian dunes seen by HiRISE. These are NOT due to liquid water but resemble in many ways the RSLs.

To bolster his argument, Dundas showed several examples of dry granular flows on Mars that exhibited many of the same properties as RSLs – recurring dark streaks, running along sloped surfaces.

Continued work will either corroborate Dundas’s striking result or circumvent it, and given the number of folks lined up to talk with him after his talk, I’m sure the fans of liquid-flow RSLs will work hard to counter his arguments. And that’s how science progresses – one falsified hypothesis at a time.

Not quite as splashy, I also gave a presentation on our work trying to de-bias dust devil surveys. I’ve posted the presentation below.

All in all, my first LPSC was a great mix of science, warm weather, and warm friends.

The last day of the meeting is always to hardest to write about because I’m usually so busy wrapping things up, I don’t have time to write (hence my writing this post from Boise on the Sunday AFTER the conference).

In any case, lots of talks and goodbyes on the last day, but one talk that stands out for me came from Andrew Hesselbeck Hesselbrock, one of David Minton‘s grad students at Purdue’s EAPS. The talk tackled one of the longest-standing mysteries in solar system science: Why hasn’t Phobos crashed into Mars yet?

Phobos (left) and Deimos (right). From http://www.planetary.brown.edu/planetary/geo287/PhobosDeimos/images/Mars%20and%20Moons.jpg.

Phobos (left) and Deimos (right).

Mars has two tiny moons, Phobos and Deimos, which visibly resemble asteroids but are probably not for a long list of reasons.

Phobos is close enough to Mars that Mars’ gravity is dragging the moon inward, similar to but in the opposite direction as the effect of the Earth’s gravity on the Moon. Phobos is so close, in fact, that astronomers expect it will spiral into Mars in just a few million years.

Phobos and Deimos have probably been orbiting Mars for about the age of the solar system, 4.6 billion year. So if this orbital decay were the whole story, it would be mean we just caught Phobos right at the end of its life, about as likely as catching someone driving from Boise to New York City right as they pass through the Holland Tunnel*. Hesselbeck Hesselbrock suggested in this talk that we’re actually seeing a recurring phase in a much more dramatic story for Phobos.

Instead of steadily spiraling in toward Mars for 4.6 billion years, Phobos (or at least a proto-Phobos) already spiraled in toward Mars before, millions of years ago. But when the satellite got close enough to Mars, Mars’ gravity ripped it apart and formed a disk of rubble around the planet. Soon after forming, this disk spread out, some moving toward Mars (and ultimately impacting the surface) and some moving away. Eventually, the bits that moved outward moved far enough away from Mars that they re-coalesced. In fact, Hesselbeck Hesselbrock speculated that Phobos has actually been reincarnated many times in this way, every time a little smaller than before, until we were left with the bitty moon we see today.

As crazy as this hypothesis sounds, it could answer several puzzles of the Martian system, including accounting for cyclic sediment deposits on Mars’ surface — the deposits form every time Phobos falls aparts and bits rain down on Mars’ surface.

Again, the annual DPS meeting astounds and amazes. Looking forward to Provo next year.


The distance from Boise to New York City is about 2,475 miles, and the Holland Tunnel is about 9,000 feet long. Assuming a uniform driving speed, the probability of catching our driver in the tunnel is roughly equal to 9,000 feet/2,475 miles ~ 0.1%. The probability of catching Phobos during a 10 million year window over the age of the solar system is about 0.2%. Of course, you’re a little more likely to catch our driver in the Holland Tunnel, given NYC’s traffic.

Fourth day of the DPS meeting, and I found myself sitting through some great plenary talks.

cvprxvsvuaeikj1First up was Kleomenis Tsiganis‘s Farinella Prize lecture “Flavors of Chaos”, a rapid-fire tour of the intricate and complex web of gravitational interactions among planets and asteroids in our solar system.

Tsiganis’s described how, using a combination of computational and pencil-and-paper techniques, we can pick at the threads in this cosmic network to tease out the early history and evolution of our solar system.

For instance, the orbits of asteroids in the asteroid belt provide subtle clues that, billions of years ago, Jupiter moved inward almost to the orbit of Mars before backing out near to its current orbit, a celestial maneuver referred to as “The Grand Tack“.

cvpbr0kusaaqdlgThis presentation was followed by Leigh Fletcher‘s Urey Prize talk about the menagerie of seasonal changes we observe in the atmospheres for all the outer planets, from Jupiter to Neptune.

The talk was full of beautiful images of the roiling and boiling of planetary atmospheres and concluded with Fletcher’s plea to send another mission to the Uranus or Neptune before he’s too old to participate (some plans from NASA have a mission launching to Uranus or Neptune sometime in the late 2020s/mid-2030s).

Finally, we had a tag-team talk from Ashwin Vasaveda and Sanjeev Gupta about new results from Mars Curiosity rover. In addition to the stupefying images, the thing that impressed me most about the talk was just the level of detail to which we can infer the geological history of Gale Crater, where Curiosity landed.

cvpm7vnuiaarkpeGupta described how the tilt of beds of sedimentary rock could be used to infer the presence of a river delta spilling out into the crater, which suggests the existence of a long-lived (millions of years) lake in the crater, probably billions of years ago when Mars was warmer and wetter.

Mars_poster

Mars will soon make its closest approach to Earth in over a decade, and Boise State’s Physics Dept will host an astronomical viewing party to celebrate on Tuesday, May 31 from 8:30p till 11p.

The event will kick off in the Multi-Purpose Classroom Building, room 101 on Boise State’s campus with a public talk on the latest science of the red planet from local planetary scientist Dr. Josh Bandfield of the Space Science Institute.

Then at 9:30p the event will move to the Boise State quad, where telescopes will be set up to view Mars, Jupiter, and Saturn.

Contact Prof. Brian Jackson (bjackson@boisestate.edu@decaelus) with questions.

Event poster available here.

Endolithic ("within-rock") life. From http://d32ogoqmya1dw8.cloudfront.net/images/microbelife/extreme/endoliths/cryptoendolith.jpg.

Endolithic (“within-rock”) life

Today, in physics, we hosted Prof. Nancy Chanover of New Mexico State Astronomy for our departmental seminar. Chanover gave a fascinating talk on her work developing acousto-optical tunable filters (AOTFs) to look for life in exotic terrestrial environments and on Mars.

AOTFs involve the application of an oscillating radio signal to a birefringent crystal. By applying the right frequency to the crystal, the crystal can be made to filter out light of very specific colors. Measuring the filtered light that comes out allows one to measure the colors of a object — is there more red light that filters through than blue, for instance?

One big advantage of these AOTFs is that they can produce spectra of rocks, minerals, anything that is colored, without any moving parts, and no moving parts is a big plus when you send an instrument to another planet.

In her talk, Prof. Chanover discussed her group’s work to develop AOTFs and techniques to analyze the emergent spectra and identify minerals on planets or moons in our solar system. Different minerals can have distinctive colors, and so taking the spectrum of a Mars rock, say, could allow us to identify its composition, without having to vaporize the rock to chemically analyze it.

The same technique could be used to look for Martian life. In some cases, extremophiles on the Earth leave tell-tale coloration in rocks (see figure at left), and so Martian life (if it exists) might do the same. Prof. Chanover’s group is looking for the distinctive spectral signatures of terrestrial biota in hopes of sending an AOTF to Mars and looking for life there, particularly in caves, which might be especially hospitable for life.

As a precursor to exploration of Martian caves, Chanover discussed her work attaching an AOTF to a robot developed by the Jet Propulsion Lab that climbs walls using footpads inspired by geckos, a LEMUR. This project involved several unforeseen challenges — as she said, on one trip, she struggled to say “acousto-optical tunable filter” in Spanish to a dubious Mexican border guard on the way to a field site in Mexico. The life of a planetary scientist.

Pressure variations (in hectoPascal, hPa) vs. local time for one dust devil pressure dip. The blue curve shows our model fit.

Pressure variations (in hectoPascal, hPa) vs. local time for one dust devil pressure dip. The blue curve shows our model fit.

Dust devils occur in arid climates on the Earth and ubiquitously on Mars. Martian dust devils have been studied with orbiting and landed spacecraft, while most studies of terrestrial dust devils have involved manned monitoring of field sites, which can be costly both in time and personnel. As an alternative approach, my colleague Ralph Lorenz and I performed a multi-year in-situ survey of terrestrial dust devils using pressure loggers deployed at El Dorado Playa in Nevada, USA, a site known for dust devil activity.

When a dust devil passed over our pressure sensors, it appeared as a pressure dip in the time series, as illustrated in the figure. By modeling these signals, we learned a lot of about dust devils. For instance, in spite of expectations, we found signals that looked a lot like dust devils that occurred at night and even in the winter. So do dust devils happen year-round, day and night? More work will help us figure it out.

Our paper on this study will appear soon in the Journal of Geophysical Research Planets.
